PM 70.5 SP PLATINUM
The models of the 70.5 SP series guarantee high performance, maximum efficiency and a high level of reliability. The articulation with the exclusive PM Double Link system guarantees an increase in the operating efficiency of the crane, which can operate with the same performance and with a constant outreach, in any vertical configuration of the machine.
Thanks to the 360 ° continuous rotation on the continuos slewing and the electronic management of the stabilization, the crane has perfect freedom of movement and constant control of the lifting capacity according to the real stability of the truck.
Basic crane configurations up to 9 extensions are possible for a maximum horizontal outreach of 22.90 m and a maximum vertical outreach of 26.50 m. The outreach width increases significantly with the new 6 extensions jibs, bringing the maximum horizontal outreach to 33.80 m and the vertical one to 36.90 m.
PLATINUM
– Cranes equipped with double link on the joints
– Multifunction radio control with color display
– Digital proportional hydraulic valve block
– Oil Cooler
– Continuous rotation on slewing ring
– PM Power Tronic electronic management system
– Color multifunction display on the base
Vehicle type
- 2 Stabilizers STANDARD
- 2 Stabilizers XL
- 4 Stabilizers
Standard equipment
![Hydraulic pull-out outrigger booms Hydraulic pull-out outrigger booms](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments-bssi.jpg)
Hydraulic pull-out outrigger booms
![Safety Kit for outriggers Safety Kit for outriggers](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments-das.jpg)
Safety Kit for outriggers
![Air/oil heat exchanger Air/oil heat exchanger](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments-sdcao.jpg)
Air/oil heat exchanger
![Sequential arm extension exit Sequential arm extension exit](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments-ussb.jpg)
Sequential arm extension exit
![Regenerative valve Regenerative valve](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments-vr.jpg)
Regenerative valve
![Double connecting rod Double connecting rod](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments-do.jpg)
Double connecting rod
![Hydraulic flip-up outriggers Hydraulic flip-up outriggers](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments-msr.jpg)
Hydraulic flip-up outriggers
![Slewing ring Slewing ring](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments-ra.jpg)
Slewing ring
![Distributore idraulico proporzionale digitale Distributore idraulico proporzionale digitale](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments.jpg)
Distributore idraulico proporzionale digitale
![Radiocomando multifunzione con display a colore Radiocomando multifunzione con display a colore](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments.jpg)
Radiocomando multifunzione con display a colore
![Distributore proporzionale comando stabilizzazione Distributore proporzionale comando stabilizzazione](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_equipments.jpg)
Distributore proporzionale comando stabilizzazione
Optional
![Jib Jib](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_optionals-ant.jpg)
Jib
![Hose reel Hose reel](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_optionals-avt.jpg)
Hose reel
![Hose racks Hose racks](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_optionals-crt.jpg)
Hose racks
![Hydraulic winch on crane Hydraulic winch on crane](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_optionals-vig.jpg)
Hydraulic winch on crane
![Tank Tank](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_optionals-sbt.jpg)
Tank
![Manual extensions Manual extensions](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_optionals-prm.jpg)
Manual extensions
![LMU CE control system for mechanical extensions LMU CE control system for mechanical extensions](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_optionals-lmu.jpg)
LMU CE control system for mechanical extensions
![Work spotlight with LED technology Work spotlight with LED technology](https://www.pm-group.eu/en/wp-content/themes/pm-group/images/pm_products_optionals-fld.jpg)
Work spotlight with LED technology
